Jet 101292 - (L90-15003) 15 Ton 11-1/2' Lift L-90 Series Chain Hoist - Super Heavy Duty

$10,591.99
SKU:
JET101292
UPC:
059629825761
Weight:
400.00 LBS
Availability:
Special Order: Usually Ships in 10-14 Business Days.
Shipping:
$199.00 (Fixed shipping cost)
Shipping:
$199.00 (Fixed shipping cost)
Qty:

Product Details

  • The strongest chain hoist available!
  • Exclusive Class V+ load chain is the world's strongest grade
  • Provides unparalleled safety for the most demanding applications
  • Chrome Molybdenum load gears for maximum strength and resistance to shock
  • Load sheave is designed for long wear with uniform pockets for correct chain contact
  • Drop forged hooks are designed to bend slowly to warn of overloads
  • Rolled edge on hand wheel cover acts as a chain guide and allows smooth operation even when pulling the hand chain at an angle
  • Positive ratchet, screw and disc are completely enclosed to protect the brake mechanism
  • Non-asbestos wet friction brake discs will not slip even when oil is present
  • Electrostatic powder coated before assembly to protect against rust and corrosion
  • Capacity unaffected by temperatures up to -40ºC with suitable winter lubrication
  • Tested to 150% of rated capacity
  • Meets OSHA and ANSI B30.16 standards (certificate included)
  • Made in Japan
  • NOTE: Custom Lifts are available in any length desired. Ask your local JET distributor for details!
  • Rated Lifting Capacity : 15 T
  • Rated Lifting Capacity : 30,000 lb
  • Standard Lift : 11-1/2'
  • Head Room : 38-7/8"
  • Number of Falls : 6
  • Load Chain Diameter : 9.0 mm
  • Force Req. to Lift Capacity : 88 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 556'
  • A: 38-7/8"
  • B: 9-1/4"
  • C: 3-9/16"
  • D: 5-11/16"
  • E: 19-3/8"
  • F: 3-13/16"
  • G: 4"
  • H: 3-7/64"
  • I: 2-7/16"
  • N: 3-3/16"
