Jet 101306 - (KCH-0520L) 1/2 Ton KCH Series Chain Hoist with Overload Protection - Heavy Duty
$513.99
Product Details
- Equipped with an automatic overload protection device as standard equipment (up to 5 tons)
- Device is factory preset to prevent serious overload of the hoist
- Actuation is automatic, requiring no input from the operator
- Triple Spur geared for efficient operation
- Grade 100 load chain for greater strength
- Exclusive premium grade, non-asbestos brake discs for longest life
- Load tested to 150% of rated capacity with certificate
- Meets ASME B30.16 standards
- ISO 9001-2000 certified factory
- NOTE: Custom Lifts are available in any length desired. Ask your local JET distributor for details!
- Rated Lifting Capacity : 1/2 T
- Rated Lifting Capacity : 1,100 lb
- Standard Lift : 20'
- Head Room : 11-1/4"
- Number of Falls : 1
- Load Chain Diameter : 5.0 mm
- Force Req. to Lift Capacity : 51 lb
- Length of Hand Chain Pulled to Lift Load 1' : 25'
- A: 5-1/8"
- B: 5-1/2"
- C: 1-5/8"
- D: 1"
- E: 27 mm
- F: 32 mm
- G: 35 mm
- H: 11-1/4"
