Buy Tools and Hardware in Canada
  • Image 1

Jet 101346 - (KCH-3020L) 3 Ton KCH Series Chain Hoist with Overload Protection - Heavy Duty

$1,168.99
SKU:
JET101346
UPC:
059629883402
Weight:
155.00 LBS
Availability:
Special Order: Usually Ships in 10-14 Business Days.
Shipping:
$199.00 (Fixed shipping cost)
Shipping:
$199.00 (Fixed shipping cost)
Qty:

Product Details

  • Equipped with an automatic overload protection device as standard equipment (up to 5 tons)
  • Device is factory preset to prevent serious overload of the hoist
  • Actuation is automatic, requiring no input from the operator
  • Triple Spur geared for efficient operation
  • Grade 100 load chain for greater strength
  • Exclusive premium grade, non-asbestos brake discs for longest life
  • Load tested to 150% of rated capacity with certificate
  • Meets ASME B30.16 standards
  • ISO 9001-2000 certified factory
  • NOTE: Custom Lifts are available in any length desired. Ask your local JET distributor for details!
  • Rated Lifting Capacity : 3 T
  • Rated Lifting Capacity : 6,600 lb
  • Standard Lift : 20'
  • Head Room : 20"
  • Number of Falls : 2
  • Load Chain Diameter : 7.1 mm
  • Force Req. to Lift Capacity : 79 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 114'
  • A: 6-5/8"
  • B: '9-1/4"
  • C: 4-1/8"
  • D: 2-1/16"
  • E: 43.5 mm
  • F: 52 mm
  • G: 62.5 mm
  • H: 20"
