Jet 101402 - (L95-0502) 1/2 Ton 10' Lift Chain Hoist - Super Heavy Duty (Overload Protection)

$822.99
SKU:
JET101402
UPC:
059629838341
Weight:
70.00 LBS
Availability:
Special Order: Usually Ships in 10-14 Business Days.
Shipping:
$65.00 (Fixed shipping cost)
Shipping:
$65.00 (Fixed shipping cost)
Qty:

Product Details

  • Series L-95 is equipped with an automatic overload protection device as standard equipment
  • Overload protection is pre-set at 120% of rated capacity
  • Exclusive Class V+ load chain is the world's strongest grade
  • Provides unparalleled safety for the most demanding applications
  • Chrome Molybdenum load gears for maximum strength and resistance to shock
  • Load sheave is designed for long wear with uniform pockets for correct chain contact
  • Sealed bearings support load and reduce operator effort
  • Drop forged hooks are designed to bend slowly to warn of overloads
  • Rolled edge on hand wheel cover acts as a chain guide and allows smooth operation even when pulling the hand chain at an angle
  • Dual pawl brake is completely enclosed to protect the brake mechanism
  • Non-asbestos wet friction brake discs will not slip even when oil is present
  • Electrostatic powder coated before assembly to protect against rust and corrosion
  • Tested to 150% of rated capacity
  • Meets OSHA and ANSI B30.16 standards (certificate included)
  • Made in Japan INSERT HAND DRAWN DIAGRAM
  • safety hooks icon
  • super heavy duty icon
  • Rated Lifting Capacity : 1/2 T
  • Rated Lifting Capacity : 1,100 lb
  • Standard Lift : 10'
  • Head Room : 10-3/4"
  • Number of Falls : 1
  • Load Chain Diameter : 5.0 mm
  • Force Req. to Lift Capacity : 49 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 29'
  • A: 10-3/4"
  • B: 6-1/8"
  • C: 2-9/16"
  • D: 3-9/16"
  • E: 5-1/2"
  • F: 1-1/8"
  • G: 1-7/16"
  • H: 21/32"
  • I: 1/2"
  • N: 1-1/32"
