Description:

• 1 HP high performance DC motor
• Reliable single board computer microprocessor for precise control
• Precise spindle speed digital readout
• Variable speed from 450 - 3,800 RPM
• 24 indexing positions with spindle lock
• Work light with 18" flex. shaft for improved visibility during intricate work
• Heavy-duty precision cast iron bed ensures stability, accepts optional extension bed for turning operations up to 44"
• Comes complete with 3" faceplate, 6" and 12" tool rests with 5/8" post diameter, MT#2 spur centre and MT#2 heavy-duty live centre, safety goggles, knock-out rod, tool storage rack, screwdriver and 4 hex. keys

Specifications:

• SWING OVER BED: 12"
• DISTANCE BETWEEN CENTRES: 18"
• SPINDLE SIZE: 1" x 8 TPI
• SPINDLE BORE: 3/8"
• SPINDLE SPEEDS: 2 (450-1,800 / 950-3,800 RPM)
• HEADSTOCK AND TAILSTOCK TAPER : MT # 2
• DC MOTOR : 1 HP / 7 Amp.
• VOLTAGE: 110V, 1 phase, 60 Hz
• ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT: 39" x 15" x 18" / 105 lbs
• PACKAGING DIMENSIONS (LXWXH) / WEIGHT: 36" x 14-1/2" x 18-3/8" / 110 lbs
