- Jet 101156 - (KCH-5020) 5 Ton 20' Lift KCH Series Chain Hoist - Heavy Duty
Product Details
- Triple spur geared for efficient operation
- Maintenance free sealed bearings reduce operator effort
- Dual pawl Weston style brake with extra heavy pawl springs for safe reliable operation
- Extra thick ratchet gear protects brake disc from contamination
- Exclusive premium grade, non-asbestos brake discs for longest life
- Grade 100 load chain for greater strength
- Top and bottom safety hooks bend slowly to warn of overloads
- Cast safety latches exceed industry standards
- Specialized finish on key internal parts for superior corrosion resistance
- Load tested to 150% of rated capacity with certificate
- Meets ASME B30.16 standards
- ISO 9001-2000 certified factory
- NOTE: Custom Lifts are available in any length desired. Ask your local JET distributor for details!
- Rated Lifting Capacity : 5 T
- Rated Lifting Capacity : 11,000 lb
- Standard Lift : 20'
- Head Room : 23-5/8"
- Number of Falls : 2
- Load Chain Diameter : 9.0 mm
- Force Req. to Lift Capacity : 83 lb
- Length of Hand Chain Pulled to Lift Load 1' : 198'
- A: 7-1/2"
- B: 11-1/8"
- C: 2-5/8"
- D: 2-1/2"
- E: 51 mm
- F: 60 mm
- G: 78 mm
- H: 23-5/8"
