    Jet 110513 - (MM320-10) 3 Ton 10' Lift Mini-Mite II Lever Chain Hoist - Super Heavy Duty

    $1,317.99
    SKU:
    JET110513
    UPC:
    059629868843
    Weight:
    92.00 LBS
    Availability:
    Special Order: Usually Ships in 10-14 Business Days.
    Shipping:
    $95.00 (Fixed shipping cost)
    Shipping:
    $95.00 (Fixed shipping cost)
    Qty:

    Product Details

    • New improved design is smaller and lighter than the original Mini Mite
    • Class V+ Chain is world's strongest and is exclusive to JET
    • Allows use of smaller load chain without compromising safety
    • Zinc coated load chain and coated brake hub minimize corrosion
    • One simple lever changes direction and disengages gear train for fast chain adjustments
    • New larger hooks with extra heavy duty latches
    • Riveted rubber handle for comfort and safety
    • Electrostatic powder painted before assembly to protect against rust
    • Capacity unaffected at temperatures up to -40°C with suitable winter lubrication
    • Tested to 150% of rated capacity
    • Meets ANSI B30.21 specifications (Certificate included)
    • Made in Japan
    • Rated Lifting Capacity : 3 T
    • Standard Lift : 10'
    • Number of Falls : 1
    • Load Chain Diameter : 9.0 mm
    • Min. Distance Between Hooks : 16-3/16"
    • Distance per Handle Pull : 1/2"
    • Force Req. to Lift Capacity : 82 lb
    • Lever Length : 14-1/8"
    • A: 16-3/16"
    • B: 7-11/32"
    • C: 7-3/32"
    • D: 3-1/4"
    • E: 4-3/32"
    • F: 6-5/8"
    • G: 14-1/8"
    • H: 1-13/32"
    • J: 2-5/64"
