- Jet 120256 - 5 Ton SBT Series Manual Trolley - Heavy Duty
Product Details
- Load is moved by pulling on hoist load chain in direction of travel
- Double sealed ball bearings for long life
- Specially hardened steel wheels meet ANSI B30.11 specifications (Certificate included)
- Specially designed integrated drop stops/bumpers take the load in the event of wheel failure and prevent wheels from contacting other trolleys on the track
- Adjustable to fit various sizes of flanges and beams
- Comes equipped for use on up to 8" beam widths
- Can be installed or removed at any point along the track
- Use on straight or curved H, I, W and S-beams
- Rated Capacity : 5 T
- Rated Capacity : 11,000 lb
- I-Beam Flange Width (H) : 4-1/2 8-1/32"
- Min. Curve Radius : 55"
- A: 15-15/32"
- B: 15-3/8"
- C: 15-29/32"
- D: 4-3/4"
- E: 13/16"
- F: 1/8"
- G: 8-3/4"
