Description:

• Powerful 3 HP Leeson motor
• Heavy-duty cast-iron table and extension tables are double ground for accuracy and finish
• Table has "T" slots for miter gauge and beveled front edge
• Large 8" diameter chromed handwheels with center locking knobs
• Magnetic safety switch
• Massive cabinet mounted trunnions and three V-belt drive system
• 50" Max rip
• Comes with riving knife, industrial "Tru-Rip" T-square rip fence system for precison cuts, laminated melamine extension table, 2 sturdy adjustable supporting legs for extension table, cast iron miter gauge with adjustable aluminum fence and flip stop, Standard and Dado inserts

Specifications:

• BLADE DIAMETER: 10"
• BLADE TILTS: Left
• DEPTH OF CUT AT 45°: 2-3/16"
• DEPTH OF CUT AT 90°: 3-1/8"
• TABLE SIZE WITH EXTENSIONS: 74-3/4" x 27"
• DIAMETER OF ARBOR: 5/8"
• ARBOR SPEED: 4,300 RPM
• MOTOR: 12.8 Amp.
• VOLTAGE: 220V, 1 phase, 60 Hz
• WEIGHT: 515 lbs
