Description:

• Powerful 3/4 HP single phase DC motor
• Variable speed gear drive
• Spindle depth fine feed control with micro downfeed dial
• Adjustable depth stop
• Rubber chip guards on ways
• Chuck guard
• Emergency stop button
• Comes with 1/2" chuck, chuck key, R8-JT#33 chuck arbor, chuck guard, 2 T-slot nuts, oil bottle, adjustment wrenches and hex. keys

Specifications:

• DRILLING CAPACITY IN CAST-IRON: 1/2"
• DRILLING CAPACITY IN STEEL: 1/2"
• MAX. DISTANCE SPINDLE NOSE TO TABLE: 11-1/4"
• SWING: 12-3/4"
• SPINDLE TAPER: R8
• SPINDLE STROKE: 7"
• VARIABLE SPEEDS (RPM): 2 (0-1,100 / 0-2,500)
• FACE MILL CAPACITY: 1-1/8"
• END MILL CAPACITY: 5/8"
• MAX. LONGITUDINAL TRAVEL: 8-1/2"
