Description:

• Designed for intricate contour sanding operations
• 2 Step activation safety switch with line voltage interruption in case of power failure
• Heavy-duty cast-iron tilting table is precision ground
• 1" to 4" rubber drums can be fitted on both ends for full use of the entire spindle
• 4" Dust chute for dust collector hook-up
• Heavy-duty oil bath gearbox with oil level sight gauge
• 10 interchangeable spindles (1/4" x 5", 3/8" x 6", 1/2" x 6", 5/8" x 6", 3/4" x 9", 1" x 9", 1-1/2" x 9", 2" x 9", 3" x 9" and 4" x 9")
• Includes 3 interchangeable table inserts and adjustment keys

Specifications:

• OSCILLATIONS PER MINUTE: 75
• OSCILLATIONS STROKE: 1-1/2"
• SPINDLE DRUM LENGTH: 10 (5" to 9")
• SPINDLE DRUM DIAMETER: 1/4" to 4"
• SPINDLE SPEEDS: 1,725 RPM
• TABLE SIZE: 24-1/4" x 24-1/4"
• MOTOR: 10 Amp. @ 110V, 5 Amp. @ 220V
• VOLTAGE: 110/220V, 1 phase, 60 Hz
• PRE-WIRED AT: 110V
• ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT: 24-1/4" x 24-1/4" x 47-1/4" / 285 lbs
