Features & Benefits:

• Requires Minimum 15 Amp Circuit
• Oil Lubricated
• Oil lubricated for cooler operation and reduced noise
• High output V-twin cast iron pump runs cooler than inline pumps and delivers maximum performance and operational life
• Big BoreTM cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise and longer operational life
• Low amperage draw reduces incidents of tripped breakers and voltage drops that cause premature motor failure
• Easy view oil gauge and large pressure gauges for quick identification
• Air pressure regulator enables easy adjustment of line pressure
• Features 3 quick connect air hose fittings
• Dual voltage toggle switch for use on 120V or 220V power sources
• Finned discharge tube promotes safe and efficient cooling
• Steel rim pneumatic tires for increased durability on the jobsite

Specifications:

• Motor --3 hp
• Pump --Oil-Lubricated
• Cut In Pressure --100 PSI
• Cut Out Pressure --125 PSI
• Tank --2 x 4 Gallon
• Performance --6 CFM @ 100 PSI
• Maximum Pressure --150 PSI
• Noise Level --76 dB(A)
• Dimensions (L x W x H, with handle )--42" x 18" x 26" (1,067 mm x 457 mm x 660 mm)
• Net Weight --160 lbs (72.6 kg)

Standard Equipment:

1/4" Quick Coupler (10TT-8)
