Jet 101224 - (L90X-1504) 1-1/2 Ton 15' Lift L-90X Series Chain Hoist - Super Heavy Duty

$1,038.99
SKU:
JET101224
UPC:
059629823668
Weight:
94.00 LBS
Availability:
Special Order: Usually Ships in 10-14 Business Days.
Shipping:
$95.00 (Fixed shipping cost)
Shipping:
$95.00 (Fixed shipping cost)
Qty:

Product Details

  • The strongest chain hoist available!
  • Exclusive Class V+ load chain is the world's strongest grade
  • Provides unparalleled safety for the most demanding applications
  • Chrome Molybdenum load gears for maximum strength and resistance to shock
  • Load sheave is designed for long wear with uniform pockets for correct chain contact
  • Drop forged hooks are designed to bend slowly to warn of overloads
  • Rolled edge on hand wheel cover acts as a chain guide and allows smooth operation even when pulling the hand chain at an angle
  • Positive ratchet, screw and disc are completely enclosed to protect the brake mechanism
  • Non-asbestos wet friction brake discs will not slip even when oil is present
  • Electrostatic powder coated before assembly to protect against rust and corrosion
  • Capacity unaffected by temperatures up to -40ºC with suitable winter lubrication
  • Tested to 150% of rated capacity
  • Meets OSHA and ANSI B30.16 standards (certificate included)
  • Made in Japan
  • NOTE: Custom Lifts are available in any length desired. Ask your local JET distributor for details!
  • Rated Lifting Capacity : 1-1/2 T
  • Rated Lifting Capacity : 3,520 lb
  • Standard Lift : 15'
  • Head Room : 13-1/4"
  • Number of Falls : 1
  • Load Chain Diameter : 7.1 mm
  • Force Req. to Lift Capacity : 91 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 60'
  • A: 13-1/4"
  • B: 6-5/8"
  • C: 2-15/16"
  • D: 3-11/16"
  • E: 7-3/16"
  • F: 1-5/16"
  • G: 1-11/16"
  • H: 7/8"
  • I: 5/8"
  • N: 1-3/16"
