Jet 101356 - (KCH-5020L) 5 Ton KCH Series Chain Hoist with Overload Protection - Heavy Duty
$1,645.99
Product Details
- Equipped with an automatic overload protection device as standard equipment (up to 5 tons)
- Device is factory preset to prevent serious overload of the hoist
- Actuation is automatic, requiring no input from the operator
- Triple Spur geared for efficient operation
- Grade 100 load chain for greater strength
- Exclusive premium grade, non-asbestos brake discs for longest life
- Load tested to 150% of rated capacity with certificate
- Meets ASME B30.16 standards
- ISO 9001-2000 certified factory
- NOTE: Custom Lifts are available in any length desired. Ask your local JET distributor for details!
- Rated Lifting Capacity : 5 T
- Rated Lifting Capacity : 11,000 lb
- Standard Lift : 20'
- Head Room : 23-5/8"
- Number of Falls : 2
- Load Chain Diameter : 9.0 mm
- Force Req. to Lift Capacity : 83 lb
- Length of Hand Chain Pulled to Lift Load 1' : 198'
- A: 7-1/2"
- B: 11-1/8"
- C: 2-5/8"
- D: 2-1/2"
- E: 51 mm
- F: 60 mm
- G: 78 mm
- H: 23-5/8"
