Jet 101336 - (KCH-2020L) 2 Ton KCH Series Chain Hoist with Overload Protection - Heavy Duty

$879.99
SKU:
JET101336
UPC:
059629883389
Weight:
120.00 LBS
Availability:
Special Order: Usually Ships in 10-14 Business Days.
Shipping:
$199.00 (Fixed shipping cost)
Shipping:
$199.00 (Fixed shipping cost)
Qty:

Product Details

  • Equipped with an automatic overload protection device as standard equipment (up to 5 tons)
  • Device is factory preset to prevent serious overload of the hoist
  • Actuation is automatic, requiring no input from the operator
  • Triple Spur geared for efficient operation
  • Grade 100 load chain for greater strength
  • Exclusive premium grade, non-asbestos brake discs for longest life
  • Load tested to 150% of rated capacity with certificate
  • Meets ASME B30.16 standards
  • ISO 9001-2000 certified factory
  • NOTE: Custom Lifts are available in any length desired. Ask your local JET distributor for details!
  • Rated Lifting Capacity : 2 T
  • Rated Lifting Capacity : 4,400 lb
  • Standard Lift : 20'
  • Head Room : 14-3/4"
  • Number of Falls : 1
  • Load Chain Diameter : 8.0 mm
  • Force Req. to Lift Capacity : 79 lb
  • Length of Hand Chain Pulled to Lift Load 1' : 70'
  • A: 7-1/4"
  • B: 8"
  • C: 2-1/2"
  • D: 1-3/8"
  • E: 37 mm
  • F: 46 mm
  • G: 52 mm
  • H: 14-3/4"
