Description:

• Powerful 1.5 HP motor
• Double drive belt system
• Table raises and lowers on four precision ground columns
• Comes complete with stand, planing knives, setting gauge and 4" dust chute for dust collector hook-up
• Jack Screw cutterhead system - Knives rest on adjustable Jack Screws; lock bar and lock screws keep knives in place
• Moulding cutterhead guide system - Specially designed for guiding the workpiece into the moulding cutters

Specifications:

• MAXIMUM PLANING WIDTH: 13"
• MAXIMUM MOULDING WIDTH: 13"
• MAXIMUM PLANING THICKNESS: 6-1/8"
• MAXIMUM MOULDING THICKNESS: 6-1/8"
• MINIMUM LENGTH OF STOCK FOR PLANING: 6.7"
• MINIMUM LENGTH OF STOCK FOR MOULDING: 6.7"
• MAXIMUM PLANING DEPTH: 1/8"
• MAXIMUM MOULDING DEPTH: 3/4"
• CUTTERHEAD SPEED: 4,500 RPM
• NUMBER OF KNIVES: 3
