Description:

• Powerful 2 HP motor
• Carbide ball bearing blade guides with rollers
• Centralized control panel and automatic shut-off
• Adjustable hydraulic downfeed control
• Precision blade tension adjustment
• Head swivels 0° to 45° in one direction
• Quick-positioning vise with fully adjustable jaws for 0° to 45° angles
• Coolant system included

Specifications:

• CUTTING CAPACITY AT 90°: Rect. 9" x 18" • Diam. 9"
• CUTTING CAPACITY AT 45°: Rect. 9" x 11" • Diam. 9"
• VARIABLE SPEEDS: 80-250 FPM
• BLADE: 131-3/4" x 1" x 0.032"
• MOTOR: 8 Amp.
• VOLTAGE: 220V, 1 phase, 60 Hz
• TABLE HEIGHT FROM FLOOR: 26"
• ASSEMBLED DIMENSIONS (LXWXH) / WEIGHT: 73" x 32" x 42" / 924 lbs
• PACKAGING DIMENSIONS (LXWXH) / WEIGHT: 75-1/2" x 29-7/8" x 42" / 1,067 lbs
