Features & Benefits:

• Hypoid Gear System Provides Increased Power Transmission
• Cutting Capacity Of 2-3/8" (60 mm)
• Ideal for Framers, Home Builders, Masons, and Contractors
• High quality, Hardened Steel Hypoid Gears do not wear like bronze-alloy worm drive gears
• High Performance Magnesium Base Plate, Blade Case and Motor Housing
• Bevel Capacity of 51.5° with Positive Stops at 22.5o, 45o and 51.5o ideal for cutting trusses and rafters
• Rafter Hook enables convenient storage on 2x materials when not in use
• Ergonomic Soft Rubber Top and Rear Grip design for vibration absorption and comfortable operation

Specifications:

• Blade Diameter --7-1/4" (185 mm)
• Arbor --5/8" (15.88 mm)
• Maximum Cutting Capacity:
• 0° --2-3/8" (60 mm)
• 45° --1-3/4" (44 mm)
• 50° --1-9/16" (40 mm)
• No Load Speed --4,500 RPM
• AMPS (120V) --15.0 A
• Vibration Level --(Unavailable)
• Noise Level --(Unavailable)
• Overall Length --17-3/4" (450 mm)
• Net Weight --13.2 lbs (6.0 kg)

Standard Equipment:

7-1/4" C.T. Blade 24CT (1 Ea. A-94530-10), Hex Wrench 6 (783204-6)
